System Parameters |
Processor&Chipset | Intel® Processor |
Memory | 1 x DDR3 /DDR4 SO-DIMM socket, 2GB/4GB/8GB/16GB |
Storage | 1 x 2.5" SATA 500GB/1TB/2TB
1 x Msata 16GB/32GB/64GB/128GB/256GB |
Cooling System | Fanless design |
BIOS | AMI 16MB DPI Flash |
Watchdog Timer | 255 level, 0~255 sec |
LAN | 1 x Realtek RT8111E, 10/100/1000M, Support PXE, Wake on Lan |
Audio | Realtek ACL662 Audio controller, Line-out, Mic-in. |
Expansion Port | 2 x MINI PCI-E full slot, 1 x SIM |
OS | Linux/ Windows XP/7/8/10/11 |
Optionals |
Printer 58mm | Optional |
QR Code Scanner | Optional |
Build-in Camera | Optional |
Spearkers | Optional |
WIFI+BT | Optional |
Display Parameters |
LCD Size | 7" ~43" TFT (LED Backlight) |
Resolution | 800*480/1024*600/1920*1080/3840*2160 |
Brightness | 350nits (1000~2200cd/m² optional) |
Aspect ratio | 16:9 |
Life Time | 50,000hrs |
Contrast Radio | (1200:1) |
Response Time | 3.5ms |
Viewing Angle | 170/160(U/D), 178/170(L/R) |
Color Resolution |  16.7M
|
Touch Screen Parameters |
Touch Type | 10 Points Capacitive Touch |
Surface Hardness | 6H>(Capacitive Touch) |
Touch Validity: | >1,000,000 |
Resolution | 4096*4096 |
Life Time | 50,000hrs |
Transparent Rate | >85% |
IO Interface |
COM | By Request |
RS422/485 | By Request |
USB | By Request |
LAN | 1 x RJ45, 10/100/1000M (2LAN Optional) |
Power Supply |
Power Supply | 12V /24 DC Power Input |
Power Comsuption | <200W |
Wide Voltage | Optional (DC 6~36V Wide Voltage ) |
Installation |
VESA | 100mm*100mm/200mm*200mm |
Stand | Optional |
Environments |
Operating Temp | -10℃~50℃ |
Storage Temp | -30℃~70℃ |
Relative Humidity | 5~95%@10℃ (Non-condensing) |
Vibration | 5~500Hz,1.5G,0.15mm peak value |
Shake | 1.5 Grms, IEC 60068-2-64, 5 ~ 500 Hz, 1 hr/axis |
Shock | 10 Grems, IEC 60068-2-64, Half sine wave,for 11 ms |
EMC | CE/FCC Class A |
Enclosure |
Housing Material | Aluminum Chassis with fanless design |
